1212 Mini Wood Door Making Carving Woodworking LEAD CNC Router Frame 2.2KW Spindle Automatic Wood Metal Carving Cutting Machine
Original price was: R32999,99.R29999,99Current price is: R29999,99.
1500x1500mm Lead CNC Machine Wood Router Set High Precise LEAD CNC Router Machine Mechanical Kit with 4pcs Nema23 Stepper Motors
Original price was: R35999,99.R31999,99Current price is: R31999,99.
1500x1500mm Lead CNC Machine Wood Router Set High Precise LEAD CNC Router Machine Mechanical Kit with 4pcs Nema23 Stepper Motors
Description
CNC Router – YuYong Industry (1500x1500mm)
Product Details
-
Machine Type: CNC Router
-
CNC or Not: CNC
-
No. of Spindles: Single Phase
-
Number of Axes: 4
-
Core Components: Bearing, Motor, Engine
-
Voltage: 110V / 220V
-
Spindle Motor Power: 1.5 / 2.2 kW
-
Range of Spindle Speed: 8,000 – 24,000 rpm
-
Positioning Accuracy: 0.05 mm
-
Repeatability (X/Y/Z): 0.05 mm
-
Z-Axis Travel: Approx. 100 mm
-
Drive System: TR8x8(P2) ACME Lead Screw
-
Motor: Stepper Motor – High Torque 2.45 N.m
-
Power: 24V, 350W Output
Working Area & Dimensions
-
Working Table Size: 1500 x 1500 mm
-
Travel (X Axis): 1230 mm
-
Travel (Y Axis): 1310 mm
-
Dimension (LWH): 1500 x 1500 mm
-
Weight: 34 kg
Build & Design
-
Frame Material: 6063-T5 Aluminum
-
